3 Humbuckers/5-Way Switch/1 Volume/1 Tone/01
$0.00
)
Product Description
3 mini Humbuckers, 5 -way lever switch, 1 Volume, 1 Tone. Three mini humbuckers with custom pickup switching. Click diagram image to open/view full size version. Ready to get started? Don't forget the Wire, Solder, Shielding & Supplies. Copyright© GuitarElectronics.com LLC. Unauthorized replication is prohibited.
