2 Humbuckers/3-Way Toggle Switch/2 Volumes/2 Tones/Coil Tap & Reverse Phase

$0.00

2 Humbuckers/3-Way Toggle Switch/2 Volumes/2 Tones/Coil Tap & Reverse Phase

$0.00
Share

Product Description

Gibson style guitar wiring diagram with 2 humbuckers, 3-way toggle switch, one volume and two tone controls, plus one push/pull switch to select humbucker or single coil mode and one push/pull switch to select reverse phase (neck). Selecting single coil mode selects the North coil of the neck pickup and the South coil of the bridge pickup. Ready to start? Don't forget the Wire, Solder, Shielding & Supplies. Copyright© GuitarElectronics.com LLC. Unauthorized use prohibited. Click diagram to view full size.

View related parts for this diagram below.
