1 Humbucker/1 Volume/1 Tone/Series-Parallel & Coil Tap South

$0.00

1 Humbucker/1 Volume/1 Tone/Series-Parallel & Coil Tap South

$0.00
Share

Product Description


Guitar wiring diagram with one humbucker and one volume and one tone with two push pull switches. Push pull on the volume selects series humbucker or parallel humbucker and the push pull on the tone coil taps the humbucker to single coil mode (South). Don't forget the Wire, Solder, Shielding & Supplies. Copyright© GuitarElectronics.com LLC. Unauthorized use prohibited. Click diagram to view full size.

Download PDF Version Download printable PDF version

Click to view wire color codes for all brands of humbuckers.
